TradeSalon | CCTV Digital Video Recorder |
---|
DVR2012A | DVR2012B |
---|---|
Features
Package:
|
Type | DVR2012A (4-line) | DVR2012B (8-line)
Screen Display
| 10.1" digital LCD display
| Operation system
| Embedded LINUS Operation system
| Operation interface
| 16 digits real color graphic menu & support USB mouse operation & menu comments
| Video compression format
| H.264
| Video resolution
| PAL: 704×576 NTSC: 704×480
| Frame rate
| PAL: 100fps
| PAL: 200fps
| Video compressed code rate
| CIF, HDI, DI
| CIF
| Video input
| 4 channel (PAL/NTSC)
| 8 channel (PA/NTSC)
| Video output
| 1/2 channel (PAL,NTSC) BNC ( composite video signal: 1.0Vp-p, 75ΩBNC
| Audio compression format
| 8kHz×16bit, ADPCM
| Audio input
| 4 channel, RCA PHONO PLUG
| 8 channel, RCA PHONO PLUG
| Audio output
| 1 channel,RCA PHONO PLUG
| Monitoring screen
| 1/4 screen display
| 1/4/9 screen display
| Local replay
| 4 channel replay simultaneously
| 1 channel replay
| Motion detect
| Detect area settings PAL 13×10 (130); NTSC 13×8(104), 4 adjustable sensitivity settings
| Network interface
| 1 RJ45 Ethernet 10M/100M
| Hard disk storage
| Support 1 to 2 hard drives ( support large capacity SATA hard drive )
| USB Ports
| 2 USB ports ( USB mouse & backup & recording using high speed USB2.0)
| VGA ports
| 1 ( optional ). resolution: 800×600, 1024×768
| Alarm input
| 4 channel alarm input
| 8 channel alarm input
| Alarm output
| 1 channel alarm output
| Feature | Support mobile phone monitoring via GPRS/CDMA/EDFE/3G network
| Power | AC100-240V, INPUT/12V@3A power adapter
| Working temperature
| 0° ~ +55°C
| Working humidity
| 10%~90%
| Atmosphere
| 86kpa~106kpa
| Dimension
| Type B: 27.0cm × 24.5cm × 4.6cm
| |
Model DVR2012C |
Real time 4 ch H.264 Network DVR
Packing size: 58.5×33×32.5 Gross Weight: 11KG |
Model DVR2012D |
Real time 8 ch H.264 Network DVR
Packing size: 58.5×33×32.5 Gross Weight: 11KG |
Model DVR2012E |
Real time 4 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 14.5KG |
Model DVR2012F |
Real time 8 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 14.5KG |
Modell DVR2012G |
Real time 16 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 14.5KG |
Model DVR2012H |
Real time 16 ch H.264 Network DVR
Packing size: 56.5×43×40 Gross Weight: 15KG |
Model DVR2012I |
Real time 4 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 14.5KG |
Model DVR2012J |
Real time 8 ch H.264 Network DVR
Packing size: 48.5×43.5×33 Gross Weight: 13KG |
Model DVR2012K |
Real time 16 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 15KG |
Model DVR2012L |
Real time 4 ch H.264 Network DVR
Packing size: 56.5×43×40 Gross Weight: 15KG |
Model DVR2012M |
Real time 4 ch H.264 Network DVR
Packing size: 56.5×43×40 Gross Weight: 15KG |
Model DVR2012N |
Real time 16 ch H.264 Network DVR
Packing size: 56.5×43×40 Gross Weight: 15KG |
Model DVR2012O |
Real time 4 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 15KG |
Model DVR2012P |
Real time 8 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 15KG |
Model DVR2012Q |
Real time 4 ch H.264 Network DVR
Packing size: 65.5×40×32.5 Gross Weight: 15KG |
Model DVR2012R |
Real time 8 ch H.264 Network DVR
Packing size: 56.5×43×40 Gross Weight: 15KG |
Model DVR2012S |
Real time 16ch H.264 Network DVR
Packing size: 56.5×43×40 Gross Weight: 15KG |
Model DVR2012T
DVR/camera combo kit
Packing size: 45×36.5×61 Gross Weight: 25kg |
Model DVR2012U
4CH D1 with HDMI, SD card ,WIFI
Gross Weight: 15kg |
Model DVR2012V
8CH D1 with HDMI, SD card ,WIFI
Gross Weight: 15kg |
Model DVR2012W
|
|
| |
Series | 8800 Series
Model Number
| TV-8816
| Operating System
| LINUX operating system
| Image Code Control
| H.264
| Dual Stream
| Every channel can set
| Video Standard
| PAL/NTSC
| Monitoring Image Quality
| D1(704*576)
| Image Dynamic Detection
| Each screen can detect 396(22×18)detection areas and set 6-level sensitivity
| Playback Image Quality
| PAL
| 16ch CIF (704×576) 400 fps
| NTSC
| 16ch CIF (720×480) 480 fps
| Region Cover
| Every channel can set 4 cover regions
| Record Mode
| Support manual, auto, dynamic detection, alarm trigger
| Recording Playback
| Support 1ch to 16ch playback simultaneously
| Video Bit Rate
| 48Kbps-2048Kbps, support user-defined, MAX 2048Kbps
| Bit Stream Type
| Composite stream/video stream
| Audio Compression Standard
| G.711A
| Audio Bit Rate
| 64kbps
| Backup Way
| Support HDD, U disk, USB mobile HDD, USB burner, network storage and backup
| Operation Way
| Mouse, remote control, front panel button, control keyboard operation
| Local Login
| User name and password
| Recording Storage
| Local HDD, network
| External Ports
| Video Input
| 16ch BNC
| Audio Input
| 4ch RCA
| Voice Talkback Input
| 1 RCA port, the same channel as the first channel of the audio input
| Video Output
| 1ch BNC, 1ch VGA (Resolution: 800×600, 1024×768 optional)
| Audio Output
| 1ch RCA
| Network Port
| 1 RJ45,10M/100M self-adaptive LAN port
| RS485 Port
| Full duplex standard 485 port, support 19 kinds PTZ protocol
| USB Port
| 3 USB 2.0 ports (one is on the front panel, the other two are on rear panel)
| Alarm Input
| 1ch
| Alarm Output
| 1ch
| Wireless Port
| 3G, WIFI
| HDD
| HDD Port
| 2 SATA HDD ports
| Max Capacity
| Every port MAX supports 2TB HDD
| Mobile Surveillance
| Support (iPhone, Windows Mobile, BlackBerry, Symbian, Android) 3G mobile phone
| Power Supply
| 12V3.5A
| Consumption
| <20W(without HDD)
| Operation Temperature
| -10°C±55°C
| Operation humidity
| 10%-90%
| Dimension
| Equipment: 350mm×240mm×70mm
| Packing: 409mm×365mm×129mm Weight(without HDD)
| N.W.1.7Kg, with packing 2.89Kg
| Carton
| Size: 675mm×425mm×385mm
Weight: 15.22Kg; 5 pcs in a carton.
| Installation Way
| Desktop installation
| |
Model DVR2012X-A | Model DVR2012X-B | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
System
Main Processor
| High performance embedded microprocessor
| Operating System
| Embedded LINUX
|
System Resources
|
Pentaplex function: live, recording, playback, backup
& remote access
| Control Mode
| Front panel, USB mouse, IR remote control, Keyboard,
Network
| Video
| Input
| 8 channel, BNC(1.0Vp-p, 75)
| 16 channel, BNC(1.0Vp-p, 75)
| Standard
| NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
| Output
| 1 TV, BNC(1.0Vp-p, 75), 1 VGA
| 1 TV, 1 Spot, BNC(1.0Vp-p, 75), 1 VGA
| Audio
| Input
| 4 channel, BNC(200-2800mV,30KΩ)
| Output
| 1 channel, BNC(200-3000mV,5KΩ)
| Bidirectional Talk
| Same with audio input channel 1
| 1 channel Input, BNC(200-2800mV,30KΩ)
| Display
| Display Split
| 1/4/8/9
| 1/4/8/9/16
| Resolution
| 1280×1024, 1280×720, 1024×768
| Tour Display
| Support
| Privacy Masking
| 4 self-defined four-sided zones for privacy masking
for each camera
| OSD
| Camera title, time, video loss, camera lock, motion detection, recording
| Recording
|
Video/Audio Compression
| H.264 / G.711
| Image Resolution
| D1/4CIF(704×576/704×480) CIF(352×288/352×240)
/ QCIF(176×144/176×120)
| Encoding Speed
| Main Stream: CIF/QCIF(1~25/30fps), D1(1~6/7fps)
| Main Stream: CIF/QCIF(1~25/30fps), 2CIF(1~12/15fps), D1(1~6/7fps)
| Bit Rate
| 32~1024Kb/s
| Image Quality
| 1~6 level(level 6 is the best, VBR effectively)
| Recording Mode
| Manual, Schedule (Regular Continuous), MD (Video
detection: Motion detection, Camera blank, Video loss), Alarm), Stop
| Recording Priority
| Manual >Alarm >MD >Regular
| Recording Interval
| 1~120 min. (default: 60 min.), Pre-record: 1~30 sec.,
Post-record: 10~300 sec.
| Video
Detection & Alarm
|
Trigger Events
|
Recording, PTZ movement, Tour, Alarm, Email, Spot
output
|
Motion Detection
|
Zones: 396(22×18), Sensitivity: 1~6 (level 6 is
highest)
|
Video Loss & Camera Blank
|
Support
|
Alarm Input
|
8 channel
|
16 channel
|
Relay Output
|
3 channel
|
Playback Back
|
Playback Channel
|
1/2/4/All
|
Search Mode
|
Time/Date, Alarm, Motion Detection & Exact search
(accurate to second)
|
Playback Functions
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next
file, Previous file, Next camera, Digital zoom(any size)Previous camera,
Full screen, Repeat, Shuffle, Backup selection,
|
Backup Mode
|
Flash drive / USB HDD / USB CD/DVD-RW / Network
download
|
Network
|
Ethernet
|
RJ-45 port (10/100M)
|
RJ-45 port (10/100/1000M)
|
Network Functions
|
TCP/IP , UDP, DHCP , DNS, IP Filter, PPPOE, DDNS,
FTP, Email, Alarm Server
|
Remote Operation
|
Monitor, PTZ control, Playback, System setting, File
download, Log information
|
Hard
Disk
|
Hard Disk
|
1 SATA port, Max 2TB HDD supported
|
Space Occupation
|
Audio: 28.8MB/H, Video: 56~500MB/H
|
HDD Management
|
Hard disk hibernation technology, HDD faulty alarm
|
Auxiliary
Interface
|
USB Interface
|
2 ports, 1 for mouse control, 1 for backup
|
RS232
|
N/A
|
Support
|
RS485
|
PTZ control
|
Environmental
|
Power Supply
|
AC 100~240 V, 50/60 Hz
|
Power Consumption
|
25W
| Working Environment
| -10℃~+55℃
/ 10~90%RH / 86~106kpa
| Dimension
| 1U, 375mm×285mm×45mm(W×D×H)
| Weight
| 2.35KG(without HDD)
| |
Model DVR2012Y | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
System
Main Processor
| High performance embedded microprocessor
| Operating System
| Embedded LINUX
| System Resources
| Pentaplex function: live, recording, playback, backup
& remote access
| Control Mode
| Front panel, USB mouse, IR remote control, Keyboard,
Network
| Video
| Input
| 24 channel, BNC(1.0Vp-p, 75)
| Standard
| NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
| Output
| 1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC(1.0Vp-p, 75)
| Audio
| Input
| 16 channel, BNC(200-2000mV, 0KΩ)
| Output
| 4 channel, BNC(200-2000mV,
| 1 channel, BNC(200-2000mV, 5KΩ)
| Bidirectional Talk
| 1 channel Input, BNC(200-3000mV, 10KΩ), 1 channel
Output, BNC(200-3000mV, 5KΩ)
| Display
| Display Split
| 1/4/8/9/1625
| 1/4/8/9/16/25
| Spot Split
| 1
| 1
| Resolution
| 1920×1080, 1280×1024, 1280×720, 1024×768
| Tour Display
| Support
| Privacy Masking
| 4 self-defined four-sided zones for privacy masking for each camera
| OSD
| Camera title, time, video loss, camera lock, motion detection, recording
| Recording
| Video/Audio Compression
| 48~4096Kb/s
| Image Resolution
| D1/4CIF(704×576/704×480) / HD1(352×576/352×480) /
2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120)
| Encoding Speed
| Main Stream: D1/HD1/2CIF/CIF(1~25/30fps)
| Extra Stream: CIF/QCIF(1~25/30fps)
| Bit Rate
| 48~4096Kb/s
| Recording Quality
| CBR, VBR(1~6 level, level 6 is the best)
|
Recording Mode
|
Manual, Schedule(Regular(Continuous), MD(Video detection: Motion
detection, Camera blank, Video loss), Alarm), Stop
| Recording Priority
| Manual >Alarm >MD >Regular
| Recording Interval
| 1~120 min. (default: 60 min.), Pre-record: 1~30 sec.,
Post-record: 10~300 sec.
| Video Detection & Alarm
| Trigger Events
| Recording, PTZ movement, Tour, Alarm, Email, Spot
output
| Motion Detection
| Zones: 396(22×18), Sensitivity: 1~6 (level 6 is
highest)
| Video Loss & Camera Blank
| Support
| Alarm Input
| 16 channel
| Relay Output
| 5 channel
| Playback Back
| Playback Channel
| 1/2/4/8/16
| Search Mode
| Time/Date, Alarm, Motion Detection & Exact search
(accurate to second)
| Playback Functions
| Play, Pause, Stop, Rewind, Fast play, Slow play, Next
file, Previous file, Next camera, Digital zoom (any size) Previous
camera, Full screen, Repeat, Shuffle, Backup selection,
| Backup Mode
| Flash drive / USB HDD / USB CD/DVD-RW / Network
download
| Network
| Ethernet
| RJ-45 port (10/100/1000M)
| Network Functions
| HTTP , TCP/IP , UPNP , RTSP, UDP, SMTP , FTP, Alarm ServerNTP , DHCP ,
DNS, IP Filter, PPPOE, DDNS,
| Remote Operation
|
Monitor, PTZ control, Playback, System setting, File
download, Log information
| Hard Disk
| 4 External SATA ports, up to 16TB
| Space Occupation
| Audio: 28.8MB/H, Video: 56~1800MB/HRW, Up to 32TB
| HDD Management
| HDD Group, HDD hibernation technology, HDD faulty alarm & Raid
(Redundancy)
| Space Occupation
| Audio: 28.8MB/H, Video: 56~500MB/H
| HDD Management
| Hard disk hibernation technology, HDD faulty alarm
| Auxiliary
Interface
| USB Interface
| 4 ports, For mouse control & backup
| RS232
| Dahua keyboard, PC communication
| RS485
| PTZ control
| Environmental
| Power Supply
| AC 100~240 V, 50/60 Hz
| Power Consumption
| 40W
| Working Environment
| -10℃~+55℃
/ 10~90%RH / 86~106kpa
| Dimension
| 2U, 440mm×460mm×89mm(W×D×H)
| Weight
| 6.5KG(without HDD)
| |
Model H264A |
100FPS 4 CH H.264
|
Model H264B |
200FPS 8CH H.264
Packing size: 48×43×32.5 Gross weight: 19.5kg |
Model H264C |
100FPS 8 CH H.264
Packing size: 48×43×32.5 Gross weight: 19.5kg |
Model H264D |
200FPS 16 CH H.264
Packing size: 48×43×32.5 Gross Weight: 19.5kg |
Model H264E |
400FPS 16 CH H.264
Packing size: 48×43×32.5 Gross Weight: 20kg |
DVRA01 | ( real-time 100 frames )
|
---|
DVRA02 |
|
---|
DVRA03 |
|
---|
DVRA04 |
|
---|
DVRA05 |
|
---|
DVRA06 |
|
---|
DVRA07 |
|
---|
DVRA08 |
|
---|
DVRA09 |
|
---|
DVRA10 |
|
---|
DVRA11 |
|
---|
DVRA12 |
|
---|
DVRA13 |
|
---|
DVRB01 Real time 4 ch H.264Network DVR
|
|
---|
DVRB02 Real time 8 ch H.264Network DVR
|
|
---|
DVRB03 Real time16 ch H.264 Network DVR
|
|
---|
DVRB04 Real time 8ch H.264 Network DVR full D1
|
|
---|
DVRB05
Real time 16ch H.264 Network DVR full D1
|
|
---|
DVRB06 | Real time 4 ch H.264Network DVR
|
---|
DVRB07 | Real time 8 ch H.264Network DVR
|
---|
DVRB08 | Real time 4 ch H.264Network DVR
|
---|
DVRB09 | Real time 8 ch H.264Network DVR
|
---|
DVRB10 |
Real time 4 ch H.264Network DVR
Audio video synchronous
|
---|
DVRB11 |
|
---|
DVRB12 | Real time 16 ch H.264 Network DVR
|
---|
DVRB13 | Real time 16 ch H.264 Network DVR
|
---|
DVRB14 | Real time 4 ch H.264 Network DVR full D1
|
---|
DVRB15 | Real time 8ch H.264 Network DVR full D1
|
---|
DVRB16 | Real time 16ch H.264 Network DVR full D1
|
---|
贸易沙龙 | Digital Video Recorder 35 % listed | About | | | More | | | Contact |
---|
